800X RALLY

COLOUR

Born from the spirit of the legendary Dakar Rally, the 800X Rally is the ultimate off-road weapon—crafted for those who crave more. Incredibly lightweight and built for pure performance, it features a high-positioned mudguard, CNC-machined upper and lower triple clamps, handlebar mounts, and front and rear hubs for unmatched durability and control. Titanium alloy footpegs and a no-rear-footrest design keep things aggressive and focused—because this machine isn't built for passengers. It’s built for the fearless.

TECHNICAL DETAILS

    • Length X Width X Height: 2267×810×1395mm

    • Wheelbase: 1545mm

    • Seat height: 890mm

    • Tank capacity: 20L

    • Curb weight: 176kg

    • Ground clearance: 293mm

    • Trail: 105mm

    • Engine type: Twin-cylinder/vertical/DOHC/water-cooled

    • Displacement: 799cc

    • Bore x stroke: 88×65.7mm

    • Compression ratio: 13:1

    • Max. power: 71kW/9000rpm

    • Max. torque: 80N·m/7500rpm

    • Fuel supply: EFI

    • Max. speed: 180km/h

    • Fuel Consumption: 4.7L/100km

    • Frame type: Diamond shape, dual-wing beam

    • Front suspension: Ø49mm, adjustable preload/damping

    • Rear suspension: Adjustable preload/damping, external airbag

    • Suspension travel: Front: 270mm/Rear: 240mm

    • Front brake: 2-piston floating calliper

    • Rear brake: 1-disc, 1-piston floating calliper

    • Front tire: 90/90-21

    • Rear tire: 140/80-18

    • Steering angle: 32°

    • Rake angle: 26.15°

    • Instrumentation: TFT
